Benefit from a centration solution using a patented convergence control technology allowing an enhanced patient experience. Very user-friendly and fast, offering precise centration results.

-Experience high reliability due to convergence control based on the ZEISS patented laser technology.
-Provide fast and precise centration results with a precision of 0.1mm.
-Decide for the proven centration solution enhancing patient experience.

* Patients request excellent and individualised service.

-Patients are becoming more demanding every day, asking for more attentive service and individual optical solutions. ZEISS makes it easy, providing you with the expertise and high-quality devices that will make your centration stand out.

* Take advantage of our expertise to benefit from higher precision and an enhanced patient experience.

-With the help of ZEISS i.Terminal 2 , lens fitting becomes comfortable and enjoyable for your patients, leading to increased patient satisfaction. It captures and calculates your patient´s individual parameters with the click of a button and a high precision - which can result in a decreased complaint rate, reduced non-adapts and relaxed vision.

* ZEISS i.Terminal 2: High reliability thanks to ZEISS patented laser technology.

-ZEISS i.Terminal 2 offers high reliability thanks to the convergence control of the laser speckle - a patented ZEISS technology2. It is very user-friendly and fast, offering precise centration results. ZEISS i.Terminal 2 captures and calculates your patient’s individual parameters with the click of a button and a precision of 0.1mm.

* ZEISS i.Terminal 2 benefits at a glance.

- Experience high reliability thanks to convergence control based on ZEISS patented laser technology.

- Provide your patients with fast and precise centration results, capturing and calculating individual parameters with the click of a button.

- Allow a comfortable to use even with children and wheel-chaired patients, due to the flexible height range of between 120 �“ 208 cm.

- Experience an easy workflow, as ZEISS i.Terminal 21 can be fully integrated into your Patient Management System via ZEISS VISUCONSULT 5003.

* Flexibility without compromise.

- ZEISS i.Terminal mobile is a digital centration solution operated with an iPad® tablet for intuitive handling, high flexibility and efficient operation in your practice.

Technical Data :

Mains voltage - 100 V to 240 V AC
Supply frequency - 50 Hz to 60 Hz
Mains fuses F1, F2 - T2.0A/E 250V 5x20 IEC 60127-2/3
Protection class- I
Overvoltage category- II
Pollution degree- II
Laser class- I according to CFR and IEC 60825- 1
Ambient conditions for intended use- Temperature:+10°C to +40°C-Rel. humidity: 30%...85% (no condensation) - Max. height (MSL):2000 m
Transport and storage conditions (in original packaging)- Temperature:-40°C to +70°C
Rel. humidity:10%...85% (no condensation) - Max. height (MSL):2000 m

Physical data :
Dimensions base - 60 cm x 60 cm
Instrument (height x width x depth) - 1250�“2100 mm x 600 mm x 600 mm
Weight - approx. 47 kg
Min. ceiling height - 2.1 m
Range of movement: Minimum eye height: 110 cm (corresponds to approx. 120 cmbody height)
Maximum eye height: 195 cm (corresponds to approx. 208 cm body height)
Lifting range: 85 cm
